- 品牌：臺意德
- 型號：TYD-168SV
- 類型：臥式注塑機
- 塑化方式：螺桿式注塑機
- 傳動方式：液壓式
- 操作方式：自動注塑機
- 加工定制：是
- 螺桿直徑：48mm
- 螺桿轉速：0-180r/min
- 射膠量：329g
- 拉桿間距：460×460mm
型號 | TYD168SV | |||
Specification | 609/168 | |||
注射部分INJECTION?UNIT | unit | A | B | C |
螺桿直徑Screw?diameter | mm | Φ45 | Φ48 | Φ52 |
螺桿長徑比Screw?L/D?Ratio | L/D | 22.4 | 21 | 19.3 |
理論注射容積Theoretical?Shot?Volume | cm3 | 318 | 362 | 425 |
注射重量（PS)Shot?weight | g | 289 | 329 | 386 |
注射壓力Injection?pressure | Mpa | 195 | 170 | 146 |
注射行程The?injection?stroke | mm | 200 | ||
螺桿轉速Screw?Speed | rpm | 0~175 | ||
鎖模部分Clamping?Unit | ||||
鎖模力Clamping?Model | KN | 1680 | ||
移模行程Slide?stroke | mm | 420 | ||
模具厚度?(最小-最大)Min-max?mould?height | mm | 180-500 | ||
拉桿內間距（寬×高）Space?between?tie?Bars | mm | 460×460 | ||
頂出力Ejector?Force | KN | 39 | ||
頂出行程Ejector?Stroke | mm | 120 | ||
頂出桿數Ejector?Number | p | 4+1 | ||
其他OTHERS | ||||
最大油泵壓力System?pressure | Mpa | 16 | ||
電機功率Pump?Motor?Power | ,? KW | 15.3 | ||
電熱功率Heating?Power | KW | 13.3 | ||
油箱容量Oil?Tank?Capacity | L | 315 | ||
外形尺寸(長×寬×高)Machine?dimensions | m | 5.1×1.4×2 | ||
機器重量Machine?weight | T | 5.4 | ||
